The VGS-T series of miniature load cells are fitted into the gearbox control rod and designed for use in clutch-less gearshift applications. During the gear change sequence the driver moves the gear lever as normal, the VGS-T series load cell detects the force applied to the gear shift lever, this force is measured by the ECU, then a series of control events take place that allows the gears to mesh with full throttle still applied.
Typical application include: Gearshift - Suspension - Steering - Pedal Force - General Testing
- Miniature Size
- ±1000N Range
- Ruggedised Construction
- 6-16V Supply
- M8 threads Standard
- ±1% Accuracy
Stainless M8 half nut included n a kit.
